1. 90°, inside 45, outside 45 cutting plastic and aluminum profile. Various angle cutting is available.
2. Right head moving is driven by motor automatically and easily. Auto brake device.
3. Micro cutting length adjustment device ensure precision and easy operation.
4. With the additional intermediate supporting mechanism of equivalent length, convenient feed and location.
5. The linear guiding pair ensures steady processing accuracy.
6. Saw blade rotates smoothly due to high accuracy main spindle.
7.
Saw blade straight feeding from
inside to outside stably and precisely by pneumatic cylinder. Optional
Hydro-pneumatic feeding cylinder is available.
8. Carbide Saw blade ensure high cutting surface precision.
9. Two hand safety operation
Parameter:
Air Pressure: 0.4-0.6MPa
Air Consumption: 200L/min
Input Voltage: 3N~50Hz 380/220V or As Customer
Specification
Input Power: 3(Kw)
Saw Blade Diameter: Φ 450
Motor Rotary Speed: 2800r/min
Cutting Height: 200(mm)
Cutting Width:
120(mm)
Cutting Length:
45° max 3700mm Min 550mm
